High Temperature Lab Sample Dyeing Machine GT-D15
Application
This machine apply for dyeing and washing color fastness testing of dyeing knitted fabric, woven fabric, yarn, cotton, loose fibre, zipper, shoe material and other high-temperature hand sample & middle sample.Its high temperature dyeing machine design for dyeing, chemical, raw material, cloth industry, can simulate actual produce condition exactly, meeting requirement technology effect.
Feature
- 1.Brushed stainless steel construction, good heat- insulated performance.
- 2.SUS316 stainless steel cup, easy to clean.
- 3.O-shaped seal ring is made from latest composite material, good high-temperature and corrosion resistance.
- 4.Equipped with high-performance programmable computer control system, establish store 10 programs, each procedure can set 10 program; can control temperature rising rate, heat preservation time, cooling rate. Making whole procedure auto control, it has alarm function while working finished, easy to operate.
- 5.Electric heating adopt high quality imported 304 stainless steel tube, has long service life.
- 6.Can be customized qty and volume of dyeing cup according to customers requirements.
Product Parameters
Key Specification
Model | GT-D15A | GT-D15B |
Cup numbers | 12 | 24 |
Oil volume | 35L | 65L |
Cup volume | 250ml or 450ml or 500ml (Option) | |
Heating method | Electric heating | |
Heating medium | Glycerinum | |
Heating power | 3 x 2KW | 3 x 3KW |
Liquor ratio | 1:5 -1:100 | |
Temperature range | RT-135℃ ( Can be adjustment ) | |
Time range | 0-99min
| |
Temperature increment | 0.6-3.5℃/min | |
Temperature reduction | 6℃/min | |
Temperature accuracy | 0.5degree | |
Rotation speed | 40r/min | |
Power supply | 3∮AC 380V 50/60HZ | |
Dimensions(LxWxH) | 820×750×1200mm | 1000×750×1200mm |
Weight | 80kg | 100kg |
Accessories
Standard accessories | 12 or 24 | Beakers (according to model) |
2pcs | Beaker plug | |
Optional accessories | Optional | Beaker rubber pad |
