GESTER Instruments high precision fuzzing and pilling tester factory for textile
-
is carefully engineered at a materials level. Factors such as reflectivity, diffusion, texture, and elasticity are taken into serious consideration.
-
The product is characterized by its corrosion resistance. It has been treated with chemical or acid-base liquid to enhance its chemical properties.
-
By removing the particles and stains out, the product works well in supplying pool owners with a clean, hygienic, and clear swimming condition.
1. GESTER Instruments fuzzing and pilling tester involves a wide variety of designing elements. They are arch type, walking posture, pressure/weight focusing point, and Gait balance analysis. It conforms to the standards of EN, ASTM, DIN, BS, JIS, etc
2. Professional after-sales service personnel of GESTER International Co.,Limited will provide service at the first time according to customer requirements. The whole surface of the product is nonconductive
3. This product is not prone to wrinkle, otherwise it will give a hard touch on the skin, and may lead to wrinkles and wrinkles on users. Its key components are made of stainless steel which is durable in use
4. This product is anti-wrinkle. The twist of the yarn is professionally treated to an appropriate level to enhance the stretchability and elasticity of the yarn. It receives popularity among customers from Europe, America, Middle East, and so on
To determine the abrasion and pilling resistance of all kinds of textile structures. Samples are rubbed against known abradents at low pressures and in continuously changing directions and the amount of abrasion or pilling is compared against standard parameters.
Key Specification
Model | GT-C13B-4 | GT-C13B-6 | GT-C13B-8 | GT-C13B-9 | ||||
Working Positions | 4 | 6 | 8 | 9 | ||||
Control Mode | PLC control and touch screen display | |||||||
Counter Range | 0~999999 times | |||||||
Test Pressure
| Abrasion Test | A）Specimen holder: (198 ±2)g B) Larger loading piece: (597±5)g C) The sum mass:（795± 7)g , for workwear , upholstery, bed linen and fabrics for technical use ( nominal pressure of 12kpa) | ||||||
A）Specimen holder: (198 ±2)g B) Smaller loading piece:(397±5)g C) The sum mass: (595± 7)g , for apparel and household textiles , excluding upholstery and bed linen (nominal pressure of 9kpa) | ||||||||
Pilling Test | A）Stainless steel loading piece: (155 ± 1) g B) Specimen holder: (260 ± 1)g C) The sum mass:（415± 2)g | |||||||
Holder Effective Diameter | A) Abrasion Holder : Φ(28.65 ± 0.05)mm | |||||||
B) Pilling Holder : Φ(90 ± 0.10)mm | ||||||||
Rotational Speed | 50± 2r/min | |||||||
Pressing Weight | Mass : (2.5 ± 0.5) kg | |||||||
Diameter: Φ(120 ± 10) mm | ||||||||
Power Supply | AC220V 50/60Hz | |||||||
Dimensions(L x W x H) | 60×55×41cm | 88×61×41cm | 90×62×41cm | 90×62×41cm | ||||
Weight | 75kg | 130kg | 145kg | 150kg | ||||
Company Features
1. We have facilities that work smoothly. Running under the supervision of highly professional staff and stringent computer monitoring, they provide the highest level of product consistency.
2. To uphold our commitment to responsible and sustainable development, we have made a long-term plan to reduce our carbon footprint and pollution on the environment.
