GESTER Instruments rubber Fabric Testing Machine manufacturers for fabric
-
is carefully engineered at a materials level. Factors such as reflectivity, diffusion, texture, and elasticity are taken into serious consideration.
-
The product is characterized by its corrosion resistance. It has been treated with chemical or acid-base liquid to enhance its chemical properties.
-
By removing the particles and stains out, the product works well in supplying pool owners with a clean, hygienic, and clear swimming condition.
1. Fabric Testing Machine is , and especially fits for the usage in . It has been granted with CE, RoHS, TUV and other certifications
2. People who used this product praised that this product has a significant impact on improving production efficiency. This helps promote business growth. Its coating has been treated by high temperature, enabling users to maintain it more easily
3. The product has been approved by many international certifications. It is manufactured to meet international safety requirements
4. As a result of the effort, this product meets the strictest performance criteria. High impact resistance is the special property of the product
To determine the abrasion and pilling resistance of all kinds of textile structures. Samples are rubbed against known abradents at low pressures and in continuously changing directions and the amount of abrasion or pilling is compared against standard parameters.
Key Specification
Model | GT-C13B-4 | GT-C13B-6 | GT-C13B-8 | GT-C13B-9 | ||||
Working Positions | 4 | 6 | 8 | 9 | ||||
Control Mode | PLC control and touch screen display | |||||||
Counter Range | 0~999999 times | |||||||
Test Pressure
| Abrasion Test | A）Specimen holder: (198 ±2)g B) Larger loading piece: (597±5)g C) The sum mass:（795± 7)g , for workwear , upholstery, bed linen and fabrics for technical use ( nominal pressure of 12kpa) | ||||||
A）Specimen holder: (198 ±2)g B) Smaller loading piece:(397±5)g C) The sum mass: (595± 7)g , for apparel and household textiles , excluding upholstery and bed linen (nominal pressure of 9kpa) | ||||||||
Pilling Test | A）Stainless steel loading piece: (155 ± 1) g B) Specimen holder: (260 ± 1)g C) The sum mass:（415± 2)g | |||||||
Holder Effective Diameter | A) Abrasion Holder : Φ(28.65 ± 0.05)mm | |||||||
B) Pilling Holder : Φ(90 ± 0.10)mm | ||||||||
Rotational Speed | 50± 2r/min | |||||||
Pressing Weight | Mass : (2.5 ± 0.5) kg | |||||||
Diameter: Φ(120 ± 10) mm | ||||||||
Power Supply | AC220V 50/60Hz | |||||||
Dimensions(L x W x H) | 60×55×41cm | 88×61×41cm | 90×62×41cm | 90×62×41cm | ||||
Weight | 75kg | 130kg | 145kg | 150kg | ||||
Company Features
1. GESTER International Co.,Limited always gets a head start when the Fabric Testing Machine trends comes. Our company has beefed up distribution in the international markets, and this strategy has paid off well. Currently, we have the number of customers that is twice than last year.
2. Our large-scale manufacturing center is equipped with complete facilities. Our state-of-art facilities have certified by ISO9001 and ISO14001, which enables the production to run in a legal and effective manner.
3. Our plant boasts a series of sophisticated facilities. These facilities are equipped with advanced technologies, which allows us to manufacture products at the highest level. GESTER International Co.,Limited is driving for the best air permeability tester company in China with great-international-influence. Please contact.
