Water Vapor Permeability & Absorption Tester GT-KC55
Application
Function 1: Under the standard stipulated (23 ± 2)°C and the (50 ± 5)% RH environment, to test water vapor permeability for vamp and upper shoe materials ( including surface and lining );
Function 2: To determine the coefficient of water vapor absorption on leather and non-leather upper. The equipment is basically composed by six stainless steel cups that are inserted in plastic base which maintain them in vertical position.
Function 3: Water Vapor Permeability and Absorption Tester to determine the resistance of a material to cracking or other types of failure at flexing creases. The method is applicable to all flexible materials and in particular leathers, coated fabrics and textiles used in footwear uppers.
Standard
EN ISO 20344 Section 6.6.2 ,6.7and 6.8; EN 344-1 Section 5.13 and annex C; EN 13515; EN 13512 ;
ISO 17699; ISO 17229; ISO5402-1; ISO 17694 ; SATRA TM 55; IULTCS/IUP 20-1;
AS/NZS 2210.2 Section 6.6.2 ,6.7and 6.8
GB/T 20991 Section 6.6.2 ,6.7and 6.8; JIS-K6545
Product Parameters
Water Vapor Permeability and Absorption Tester Key Specification
Model | GT-KC55 | |
Water Vapor Permeability | Testing condition | Temperature: (23 ± 2)°C Humidity: (50 ± 5)% RH |
Testing bottle number | 6pcs | |
Bottle mouth diameter | 30mm | |
Bottles holder speed | 75 ±5cpm | |
Fan blades | 90 x 75 mm, 3 flat blades in planes inclined at 120° to each other | |
Fan rotate speed | (1400 ± 100) r/min | |
Specimen size | ￠34mm | |
Water Vapor Absorption | Cup number | 6pcs |
Volume of testing cup | 100ml | |
Inner diameter of hole | ￠35mm | |
Sample size | ￠43 mm | |
Bally Resistance Flexing | Test position | 6pcs |
Flexing angle | 22.5° ± 0.5° | |
Flexing speed | 100 ± 5 cycles / flexes per minute | |
Sample size | 70 ± 5 x 45 ± 5 mm | |
Control system | Programmable Microprocessor Control | |
Temperature range | -40~100℃ | |
Humidity range | 20%～98%RH | |
Inside dimension | 225L | |
Outside dimension WxHxD(cm) | 100x161X117cm | |
Power supply | 1∮AC220V 50/60HZ | |
Option Accessories
GT-D10 Drying Oven |
GT-KD20 Pneumatic Sample Cutting Machine (cutter: 70 ± 5 x 45 ± 5 mm,and ￠34mm,￠43 mm) |
