AATCC TM16 Suntest & Xenon Arc Tester GT-D01
Application
The Suntest & Xenon Arc Testers is a powerful Xenon Instrument for conducting accelerated tests of light fastness and photo stability tests.It is designed as a tabletop unit with a microprocessor controller for simple operation.
Feature
- 1.Air cooled Xenon lamp with 1.5 KW Measure, control and display of irradiance energy from 250 to 765 W/m²
- 2.Measure, control and display of black panel temperature ( BPT/BST) from 30℃ to 90℃.
- 3.Measure and display of test chamber temperature.
- 4.Measure, control and display of relative humidity % RH.
- 5.Setting and display the testing cumulative energy KJ/m².
- 6.Record the used hours of Xenon lamp.
- 7.Microprocessor control with data display, Programming with keyboard.
Product Parameters
Key Specification
Model | GT-D01 |
Test Mode | Timing Mode and Energy Mode |
Xenon Lamp | 1.5 KW Life Time: 500 hours |
Humidity | 30-95%RH |
BPT/BST | 35℃ to 100℃ |
Irradiance Monitoring | 1.1W/m²@420nm |
Specimen Exposure Area | 200×280mm |
Noise Level | Max.70dB(A) |
Power Supply | AC 220V 50/60HZ 4kw |
Dimensions | 1080×700×950 mm(W×D×H) |
Weight | 56kg |
Standards | AATCC TM16- Option 3 |
Accessories
Standard accessories | 1pc | Xenon Lamp |
1pc | Light Filter | |
1set | Clamp | |
1pc | Water Tank | |
1pc | Power Line | |
Optional accessories | Optional | Extra Xenon Lamp |
Optional | Extra Light Filter |
